Redline MX EXPERT
Redline
$899.00
(No reviews yet)
Write a Review
Redline
Redline MX EXPERT
Made for your growing BMX racer, the Redline MX Expert is top of class for value and quality. Aluminum alloy rims, Vee Speedster 20 × 1 3/8 inch tires, Redline premium aluminum frame, and an integrated head tube all come together to make the Redline MX Expert lightweight and easy to maneuver. The MX Expert features a high-quality 3-piece crank set, integrated headset, and pivotal race saddle. Fits riders 60 to 64 inches tall.
Specifications
- Frame - 6061 Alloy w/Integrated Headtube
- Fork - RL Race Hi-Ten w/ Tapered legs
- Headset - Integrated 1 1/8"
- Cranks - Race Aluminum 3pc, 165mm
- Sprocket - 39t, Alloy
- Bottom bracket - Euro
- Cogset - 15t
- Chain - KMC S1
- Front hub - Redline Aluminum
- Rear hub - RL Aluminum Flip-Flop
- Spokes - 14g Steel
- Rims - Alloy Race 20 x 1 1/8, 36h
- Tyres - Vee Speedster, 20 x 1 3/8
- Brake levers - Tektro
- Pedals - RL Race 9/16" PC pedal
- Handlebar - RL Race 5.5" Rise/ 12 deg Back/ 1 deg Up
- Grips - Redline Hex expert w/plugs
- Stem - RL Hollow Point Aluminum 1 1/8" threadless
- Seat - Pivotal Race
- Seatpost - Pivotal 26.8
- Brakes - Tektro BX-1V Linear
Geometry
- Frame Size - 20"
- Bike Top Tube Length - 19.5 "
- Bike Head Angle - 73.0 °
- Bike Seat Angle - 69.0 °
- Bike Chain Stay Length - 13.75 "
- Bike Bb Height - 11.4 "
- Bike Stem Length - 50.0 mm
- Bike Handlebar Width - 26.0 "
- Bike Crank Length - 165.0 mm
